MC054-5A/I-S5 5-lead ECG trunk cable,AHA/IEC , Round 10pin female,with 4.7k resistance
Applicable User
- Anesthesiologists and CRNAs managing perioperative cardiac monitoring.
- ICU nurses and clinicians overseeing critically ill patients.
- Biomedical technicians maintaining GE Datex Ohmeda S5 equipment.
Main Structure
- Connector End: 10-pin female connector with 4.7k resistance (GE Datex Ohmeda S5 monitor side).
- Lead Ports: 5 color-coded ports (RA, LA, LL, RL, V) for AHA/IEC electrodes.
- Conductors: Shielded OFC with 26AWG gauge for optimal signal-to-noise ratio.
- Jacket: Latex-free, TPU.
Intended Use
Designed to transmit 5-lead ECG signals from electrodes to GE Datex Ohmeda S5 monitors, supporting real-time detection of cardiac abnormalities, arrhythmia monitoring, and perioperative cardiac function assessment.
This trunk cable serves as the vital bridge between GE Datex Ohmeda S5 monitors and 5-lead ECG electrodes, translating cardiac electrical activity into actionable clinical data. The round 10-pin female connector (with 4.7k resistance) locks securely into S5 monitors, while color-coded AHA/IEC lead ports simplify electrode connection-reducing setup time by 30% in anesthesia or ICU scenarios .
Technical Specification
| Parameter | Specification |
| Model no. | MC054-5A/I-S5 |
| Cable Type | 5-Lead ECG Trunk Cable (AHA/IEC Compatible) |
| Connector Configuration | Round 10-pin Female (GE Datex Ohmeda S5 Monitor End) → 5 AHA/IEC Lead Ports |
| Resistance | 4.7kΩ (Ensures Signal Compatibility with S5 Monitors) |
| Length | Customizable (Standard: 2.75m) |
| Compatibility | Datex-Ohmeda AS/3, CS/3,Cardiocap , Saltite plus, S/5 light monitor |
| Minimum Order Quantiy | 1 pc |
Features
-
4.7k Resistance Precision
Built-in 4.7kΩ resistance matches GE Datex Ohmeda S5's signal requirements, eliminating "lead off" errors and ensuring continuous, reliable monitoring during surgery.
-
10-Pin Latch-Lock Reliability
The connector's secure latch design prevents accidental disconnection during patient transfers or surgical position changes.
-
Dual AHA/IEC Compliance
Color-coded lead ports (RA: White, LA: Black, LL: Red, RL: Green, V: Brown) support both AHA and IEC electrode standards, streamlining global clinical workflows.
-
Clinical-Grade Durability
PVC jacket resists tearing, chemical degradation, and EMI interference-ideal for operating rooms and ICUs.
Application Scenarios
Applicable Industry
- Hospitals & Perioperative Suites
- Intensive Care Units (ICUs)
- Anesthesia Clinics & Surgical Centers
- Biomedical Equipment Suppliers & Distributors
Applicable Fields
- Anesthesia: Real-time ECG monitoring during general anesthesia to detect arrhythmias or ischemia.
- ICU: Continuous 5-lead monitoring for post-surgical or septic shock patients.
- Cardiac Surgery: Intraoperative cardiac rhythm assessment during bypass or valve procedures.
- Emergency Medicine: Rapid arrhythmia detection in trauma or cardiac arrest scenarios.
Purpose
This cable serves as the cardiac data lifeline for GE Datex Ohmeda S5 monitors, enabling:
- Real-time detection of life-threatening arrhythmias (e.g., ventricular tachycardia) during surgery.
- Assessment of myocardial ischemia in high-risk patients (e.g., those with CAD).
- Compliance with perioperative monitoring protocols to ensure patient safety.
Pictures
Usage Method
- Pre-Use Inspection Check the cable for damage (fraying, bent pins). Ensure the 4.7kΩ resistor is intact (test with a multimeter if needed).
- Connect to Monitor Align the 10-pin connector with the GE Datex Ohmeda S5's ECG port and push until the latch clicks.
- Attach Electrodes Connect 5-lead AHA/IEC electrodes to the cable's color-coded ports, then apply electrodes to the patient (per clinical guidelines: RA - Right Arm, LA - Left Arm, LL - Left Leg, RL - Right Leg, V - V4).
- Power On and Verify Turn on the monitor. Confirm all 5 leads display clear, artifact-free waveforms. Adjust cable tension to avoid pulling on electrodes.
Summary
5-lead ECG Trunk Cable for GE Datex Ohmeda S5
This ECG trunk cable is more than a connection-it's a guardian of perioperative cardiac safety. With 4.7kΩ precision, AHA/IEC compatibility, and GE-perfect integration, it ensures clinicians get the accurate ECG data needed to navigate high-stakes surgical and critical care scenarios. Backed by our engineering expertise, strict quality controls, and global certifications, it's the trusted choice for hospitals, surgical centers, and distributors prioritizing cardiac monitoring excellence.
Whether you need to equip an operating room or supply a fleet of mobile anesthesia carts, our flexible ordering, fast lead times (5–7 days), and unwavering quality make us your ideal partner in medical connectivity.
