Technical Specifications:
| Cable Color | Gray |
| Cable Diameter | 4 mm |
| Cable Material | TPU Jacket |
| Category | SpO2 |
| Connector Distal | 6pin |
| Connector Proximal | Adult Clip |
| Latex-free | Yes |
| Packaging Type | Bag |
| Packaging Unit | 1 |
| Patient Size | Adult (>40Kg) |
| spo2 Technology | Digital |
| Sterile | NO |
| Total cable Length | 3m |
| Warranty | 12 months |
Process flow
1.Wire cutting -- 2.Sheath Stripping -- 3.Shield Twisting -- 4.Sleeve Crimping -- 5.Tin soldering -- 6.End Pressing -- 7.Set Plastic Shell -- 8.Electrical Test -- 9.Internal Mold Forming -- 10.Outer Mold Forming -- 11.Visual Inspection -- 12.Electrical Test -- 13.Thread end of network -- 14.Sheath tripping -- 15.Shield twisting -- 16.Tin soldering -- 17.Chips welding -- 18.Glue dispensing --19.Assembly -- 20.Final test -- 21.Package
Reminder:
when you select the Spo2 sensor, please check carefully the below points:
1. If the Spo2 sensor connector is really compatible to your patient monitor socket,such as 8pin or 9pin.
2. If there's different spo2 moudle for one same type patient monitor, such as the popular spo2 moudle like nellcor, massimo, and so on.
3. If the sensor is used for the right people? such as for adult or neonate.
4. When you select the short cable spo2 sensor,please check if you have the adapter cable in hand,if you have not,you can select it in our store. They need connecting together to work.
5. If you have special purpose, please let me know,we will try to offer you the professional service and instruction.
【Key technical parameter】
- Range of pulse rate(30～245)bpm:±3bpm.
- 90%-100%SpO2:±2digits;
- Range of wavelength for LED of red light:660nm(±3nm).
- Range of wavelength for LED of infrared light:905nm(±3nm).
【Working environment】
- Operation temperature:+5℃～+40℃
- Storage/transportation temperature:-20℃-+70℃
- Humidity:10%～80%(no condensation)
- Atmospheric pressure:86kPa～106kPa
Our Main Products:
1. Reusable/Disposable Spo2 Sensor
2. Spo2 extension cable
3. ECG trunk cable &leadwire
4. EKG Cable&Accessories
5. ECG electrodes
6. EEG Leadwires with electrodes
7. IBP Cable/Disposable IBP transducer
8. Water trap
9. NIBP cuff/hose/connecor
10. Temperature Probe
11. Medical battery and O2 cell
12. TOCO and US transducer
